SPECIFICATION :
24 INCH SS. TURBO VENTILATOR WITH ALUMINIUM PROFILE BASE
SL.
NO
SPECIFICATION REQUIREMENTS
DETAILS BY SUPPLIER
1.
Dimensions of Turbo Ventilator
Acs – SS 304
2.
Blade material
SS 304
3.
Number of blade
46 nos
4.
Blade thickness
0.30mm
5.
Top cover material with size
SS 304 (420mm)
6.
Bottom ring material with size
SS (610mm)
7.
Bottom ring cross material with sizes
2mm SS (610mm)
8.
Center shaft material with sizes
12mm SS
9.
Bearing number, type of seal and make
2 nos (HCH 6100 RS)
10.
Type of fastening and material of fastener
Solid Rivits (Aluminium)
11.
Minimum operation wind speed in kmph
0.50km - 125 RAM
12.
Maximum sustain wind speed in kmph
10 Km - 1420 RAM
13.
Total weight of Turbo Ventilator
4.3 Kgs
14.
Aluminum profile base dimensions and thickness
1mm (1220 x 1.06)
15.
Aluminum profile base Installation area and type of mount
Full covered with seal end
16.
Total height of turbo ventilator with base
875mm
17.
Product warranty period
24 months
18.
Service warranty period
24 months
Sl.
no
SPECIFICATION FOR FIBRE BASE
DETAILS BY SUPPLIER
1.
PROFILE
Any Profile
2.
Thickness
2 mm
3.
Length
1.6 mtrs
4.
Width
As per profile
5.
Colour
Grey
24 INCH SS. TURBO VENTILATOR WITH ALUMINIUM PROFILE BASE
|
SL. NO |
SPECIFICATION REQUIREMENTS |
DETAILS BY SUPPLIER |
|
1. |
Dimensions of Turbo Ventilator |
Acs – SS 304 |
|
2. |
Blade material |
SS 304 |
|
3. |
Number of blade |
46 nos |
|
4. |
Blade thickness |
0.30mm |
|
5. |
Top cover material with size |
SS 304 (420mm) |
|
6. |
Bottom ring material with size |
SS (610mm) |
|
7. |
Bottom ring cross material with sizes |
2mm SS (610mm) |
|
8. |
Center shaft material with sizes |
12mm SS |
|
9. |
Bearing number, type of seal and make |
2 nos (HCH 6100 RS) |
|
10. |
Type of fastening and material of fastener |
Solid Rivits (Aluminium) |
|
11. |
Minimum operation wind speed in kmph |
0.50km - 125 RAM |
|
12. |
Maximum sustain wind speed in kmph |
10 Km - 1420 RAM |
|
13. |
Total weight of Turbo Ventilator |
4.3 Kgs |
|
14. |
Aluminum profile base dimensions and thickness |
1mm (1220 x 1.06) |
|
15. |
Aluminum profile base Installation area and type of mount |
Full covered with seal end |
|
16. |
Total height of turbo ventilator with base |
875mm |
|
17. |
Product warranty period |
24 months |
|
18. |
Service warranty period |
24 months |
|
Sl. no |
SPECIFICATION FOR FIBRE BASE
|
DETAILS BY SUPPLIER |
|
1. |
PROFILE |
Any Profile |
|
2. |
Thickness |
2 mm |
|
3. |
Length |
1.6 mtrs |
|
4. |
Width |
As per profile |
|
5. |
Colour |
Grey |
